FLEX ANALOG, 12BIT, 4IN/2OUT.
Description: The Allen-Bradley 1794-IE4XOE2 is a Flex IO combination analog I/O module. This module features Four (4) single-ended, non-isolated Current and voltage analog input channels configurable for 0-20 and 4-20 mA and +/-10VDC and 0-10 VDC, respectively. It also has Two (2) single-ended non-isolated analog output channels configurable for 0-20 and 4-20 mA and +/- 10VDC. This module requires use of 1794-TB2, -TB3, -TB3S, -TB3T, -TB3TS Terminal Base Units.
| Product Description: |
Flex IO combination analog I/O module |
| Brand: |
Allen-Bradley |
| Part Number/Catalog No. |
:1794-IE4XOE2 |
| Conversion Type: |
Pulse Width Modulation (PWM) |
| Resolution: |
12 bit plus sign |
| Product Type: |
Flex I/O High-Density Analog Module |
| Inputs: |
4 Single-ended |
